The information below is specific to the Suzuki - 125 EN 125-2A (Cast Wheels), showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Suzuki - EN 125-2A (Cast Wheels) 03
Bike Info
CC:
125
Service
Chain Freeplay mm:
20
Engine Oil Classification API:
SG
Engine Oil Grade SAE:
10w40
Engine Oil quantity (litres):
1.00
Engine Oil quantity with filter (litres):
1.15
Fork oil grade:
SAE 40
Front Fork Oil cc (left leg):
150cc
Front Fork Oil cc (right leg):
150cc
Idle Speed (rpm):
1450
Spark Plugs Gap (mm):
0.6 - 0.7
Tyre Pressure Back Bar / psi:
2.0/29
Tyre Pressure Back - Pillion Bar / psi:
2.0
Tyre Pressure Front Bar / psi:
1.75/25
Brakes
Front:
Disc
Rear:
Drum
Brake fluid:
DOT 3/DOT 4
Dimensions
Dry Weight:
122kg
Fuel Capacity:
14L
Ground Clearance:
160mm
Height:
1070
Length:
1945mm
Reserve Fuel Capacity:
2L
Seat Height:
746
Wheelbase:
1265mm
Width:
735mm
Electrics
Voltage:
12v
Battery:
12v 8Ah
Bulb-Headlight:
12v 35w/35w
Ignition:
Transistor
Ignition Timing:
CDI
Main Fuse:
15A
Spark Plugs:
NGK CR7 8 or 9E,
Engine
Type:
Air Cooled 4 Stroke SOHC Single
Air Filtration:
Polyurethane Foam
Bore x Stroke:
57mm x 48.8mm
Carburation:
Mikuni BS26SS
Carburation Idle Jet:
12.5
Carburation Main Jet:
110
Compression Ratio:
9.5:1
Displacement:
124ml
Fuel Minimum Octane Rating:
91
Lubrication System:
Pressure and Splash
No. of Valves:
2
Red line RPM:
10,000
Starting:
Electric
Transmission
Chain Number of Links:
118
Chain type:
428H
Clutch Type:
wet
Final Drive:
3,214
Gearchange Pattern:
1N2345
Gear Ratio 1st:
3.000
Gear Ratio 2nd:
1.857
Gear Ratio 3rd:
1.368
Gear Ratio 4th:
1.143
Gear Ratio 5th:
0.957
Primary Drive:
3.470
Sprocket front:
14
Sprocket rear:
45
Transmission:
5 speed
Misc.
Colour Options:
Blue, Red, Black/Gray
Frame:
Tubular, single cradle
Fuel Control:
Tap
Motorcycle Style:
Naked commuter
Place of Manufacture:
China
Power
Fuel Consumption:
100mpg
Max Power Output:
12.5 Ps / 13.5 HP @ 9,500 RPM
Max Torque:
8.9 Nm @ 8,500RPM
Top Speed:
120kmh
Suspension
Front:
Telescopic forks
Rear:
Adjustable Dual Shocks
Tyres
Front:
80/90-18r, 48 Ply
Rear:
90/90-18r, 51 Ply
