Spec Sheet
The information below is specific to the Suzuki - GSX 250 SZ 82, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Bike Info
CC:
250
Brakes
Front:
Disc
Rear:
Drum
Front Disc Size:
275mm
Rear Drum Size:
160 mm
Dimensions
Dry Weight:
153 kg
Height:
1090 mm
Length:
2060 mm
Trail:
100 mm
Wheelbase:
1360 mm
Width:
755 mm
Electrics
Voltage:
12v
Ignition:
electronic inductive
Engine
Type:
Air Cooled 4 Stroke DOHC Parallel Twin
Bore x Stroke:
60 x 44.2 mm
Carburation:
2 x 30mm Mikuni CV
Compression Ratio:
10.5:1
Displacement:
249 cc
No. of Valves:
8
Starting:
electric
Transmission
Chain Number of Links:
104
Chain type:
a link one
Clutch Type:
wet multiplate
Final Drive:
520 chain
Gearchange Pattern:
1 N 2 3 4 5 6
Sprocket front:
15
Sprocket rear:
46
Transmission:
Six Speed, Manual
Misc.
Frame:
duplec steel tubular cradle
Motorcycle Style:
ROADSTER
Power
Max Power Output:
29 hp / 10,000 rpm
Max Torque:
6,5 kg-m/ 8,000 rpm
Top Speed:
about 140km/h
Suspension
Front:
Telescopic Forks 33mm
Rear:
twin shock
Tyres
Front:
300-S18 Tubed
Rear:
350-18 Tubed
Wheels
Front:
Cast Alloy
Rear:
Cast Alloy
