Spec Sheet
The information below is specific to the Suzuki - GS 850 GP 80, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Bike Info
CC:
850
Bike Description:
Bored out GS750 motor with shaft drive in modified GS1000 frame.
Service
Engine Oil Grade SAE:
10/40W
Final Drive grade:
90W
Front Fork Oil cc (left leg):
249 ml
Front Fork Oil cc (right leg):
249 ml
Tyre Pressure Back Bar / psi:
30
Tyre Pressure Back - Pillion Bar / psi:
34
Tyre Pressure Front Bar / psi:
28
Tyre Pressure Front - Pillion Bar / psi:
30
Brakes
Front:
Twin Disc
Rear:
Disc
Front Disc Size:
275mm
Front-Pistons-per-caliper:
1
Rear Disc Size:
275mm
Rear-Pistons-per-caliper:
1
Dimensions
Dry Weight:
253 kilos
Fuel Capacity:
22 litres
Ground Clearance:
160 mm
Height:
1145 mm
Length:
2235 mm
Seat Height:
785 mm
Wet Weight:
253 kg
Wheelbase:
1490 mm
Width:
735 mm
Electrics
Voltage:
12v
Battery:
YB14 L-A2
Main Fuse:
30A
Spark Plugs:
NGK B8ES/BR8ES
Engine
Type:
Air Cooled 4 Stroke DOHC Inline Four
Bore x Stroke:
69 x 56.4 mm
Displacement:
843 cc
Firing Order:
1-2-4-3
No. of Valves:
8
Starting:
electric and kick start
Transmission
Clutch Type:
Wet multiplate
Final Drive:
Shaft
Transmission:
5 Speed
Misc.
Colour Options:
Blue, Black or Red
Motorcycle Style:
Tourer
Power
Max Torque:
78 hp
Top Speed:
198 km/h
Suspension
Front:
Telescopic Forks
Rear:
Twin Shock
Tyres
Front:
100/90-H19 Tubeless
Rear:
130/90-V17 Tubeless
Wheels
Bearing Front Left:
15x42x13
Bearing Front Right:
15x42x13
Front:
19 inch alloy
Rear:
17 inch alloy
