Suzuki - SV 1000 SK3 03

picture of bike Do you have any images of this bike? Upload them here

Bike Info

CC:
1000
SV 1000 SK3 Parts and accessories

Service

Chain Freeplay mm:
20 - 30 mm
Cooling System (litres):
2.2
Engine Oil Classification API:
sg
Engine Oil Grade SAE:
10w/40
Engine Oil quantity with filter (litres):
2.9
Fork oil grade:
5w
Front Fork Oil cc (left leg):
147
Front Fork Oil cc (right leg):
147
Idle Speed (rpm):
1200 - 1300
Spark Plugs Gap (mm):
0.6 - 0.7 mm
Tyre Pressure Back Bar / psi:
36
Tyre Pressure Back - Pillion Bar / psi:
42
Tyre Pressure Front Bar / psi:
36
Tyre Pressure Front - Pillion Bar / psi:
36
Valve Clearance Cold - Exhaust:
0.20 - 0.30
Valve Clearance Cold - Inlet:
0.10 - 0.20

Brakes

Front:
Twin Disc
Rear:
Disc

Dimensions

Dry Weight:
189 kilos
Fuel Capacity:
17.0 l
Ground Clearance:
150 mm
Height:
1170 mm
Length:
2130 mm
Rake:
24.5°
Seat Height:
810 mm
Trail:
98 mm
Wheelbase:
1430 mm
Width:
745 mm

Electrics

Voltage:
12v
Battery:
YTX14-BS
Bulb-Headlight:
60/55W x 2
Ignition:
Electronic
Spark Plugs:
NGK CR8EK
Spark Plugs (Iridium):
NGK CR8EIX

Engine

Type:
Liquid Cooled 4 Stroke DOHC V Twin
Air Filtration:
Non-woven fabric element
Bore x Stroke:
98 X 66 mm
Compression Ratio:
11.3:1
Displacement:
996 cc
Fuel Minimum Octane Rating:
91
Lubrication System:
Wet sump
No. of Valves:
8
Starting:
Electric

Transmission

Chain Number of Links:
108
Chain type:
530
Clutch Type:
Wet multi-plate
Final Drive:
Chain
Gearchange Pattern:
1 N 2 3 4 5 6
Gear Ratio 1st:
2.666 (32/12)
Gear Ratio 2nd:
1.933 (29/15)
Gear Ratio 3rd:
1.500 (27/18)
Gear Ratio 4th:
1.227 (27/22)
Gear Ratio 5th:
1.086 (25/23)
Gear Ratio 6th:
1.000 (24/24)
Primary Drive Ratio:
1.838 (57/31)
Sprocket front:
17
Sprocket rear:
40
Transmission:
6 speed constant mesh

Misc.

Insurance Group:
14
Motorcycle Style:
Sports
Place of Manufacture:
Japan

Power

Max Power Output:
107 hp (85,4 kW)/ 8.500 rpm

Suspension

Front:
Inverted telescopic, coil spring, oil damped
Rear:
Coil spring, oil damped.

Tyres

Front:
120/70-ZR17 Tubeless
Rear:
180/55-ZR17 Tubeless

Wheels

Front:
17"
Rear:
17"
