Suzuki - GS 550 N 78

picture of bike Do you have any images of this bike? Upload them here

Bike Info

CC:
550
GS 550 N Parts and accessories

Service

Chain Freeplay mm:
20 - 30
Engine Oil Grade SAE:
10W-40
Engine Oil quantity (litres):
2.4
Engine Oil quantity with filter (litres):
2.6
Float Height:
26 +- 1 mm
Fork oil grade:
10W/30
Front Fork Oil cc (left leg):
165
Front Fork Oil cc (right leg):
165
Idle Speed (rpm):
1000 - 1200
Points Gap mm:
0.3 - 0.4 mm
Spark Plugs Gap (mm):
0.6-0.8
Tyre Pressure Back Bar / psi:
2.00
Tyre Pressure Front Bar / psi:
1.75 / 24
Valve Clearance Cold - Exhaust:
0.03 - 0.08
Valve Clearance Cold - Inlet:
0.03 - 0.08

Brakes

Front:
Twin Disc

Dimensions

Dry Weight:
196 kg
Fuel Capacity:
16 Litres
Height:
1150 mm
Length:
2175 mm
Reserve Fuel Capacity:
4 Litres
Wheelbase:
1435 mm
Width:
850 mm

Electrics

Voltage:
12v
Main Fuse:
15 amp
Spark Plugs:
NGK B8ES


Engine

Type:
Air Cooled 4 Stroke DOHC Four
Bore x Stroke:
56 x 55.8 mm
Displacement:
549 cc
No. of Valves:
8

Transmission

Chain Number of Links:
110
Chain type:
50
Sprocket front:
13
Sprocket rear:
50

Misc.

Motorcycle Style:
ROADSTER

Power

Max Power Output:
49 hp (35,8 kW) / 9.000 rpm
Max Torque:
42 Nm / 7.500 rpm.

Tyres

Front:
100/90-19 Tubeless
Rear:
120/90-V18 Tubeless
