Suzuki - GT 750 L 74

picture of bike Do you have any images of this bike? Upload them here

Bike Info

CC:
750
Bike Description:
L and M model had Increased Ground Clearance when lent over in Corners and power increase over K model.
Chassis info:
L model frame number fom 40247 M model frame number from 52823.
GT 750 L Parts and accessories

Brakes

Front:
Twin Disc
Rear:
Drum
Front Disc Size:
295 mm

Dimensions

Dry Weight:
214 kg (470 lbs)
Ground Clearance:
140 mm (5.5 in)
Height:
1,125mm (44.3 in)
Length:
2,215 mm (87.2 in)
Wheelbase:
1,460 mm (57.5 in)
Width:
865 mm (34.0 in)

Electrics

Voltage:
12v
Spark Plugs:
NGK B9ES

Engine

Type:
Liquid Cooled 2 Stroke Inline Traverse Triple
Bore x Stroke:
70.0 x 64.0 mm
Carburation:
40mm Mikuni CV type x 3
Compression Ratio:
6.7:1
Displacement:
738 cc

Transmission

Chain Number of Links:
108
Final Drive:
Chain
Sprocket front:
16
Sprocket rear:
44
Transmission:
5 Speed

Misc.

Exhaust:
3 into 4
Motorcycle Style:
ROADSTER

Power

Max Power Output:
67 hp/ 6,500 rpm
Max Torque:
7.7 kg-m/ 5,500 rpm.
Top Speed:
120 MPH

Tyres

Front:
3.25 x 19
Rear:
4.00 x 18
