Spec Sheet
The information below is specific to the Suzuki - GSXR 1000 K1 01, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Suzuki - GSXR 1000 K1 01
Bike Info
CC:
1000
Chassis info:
js1gt74a012100486
Service
Cooling System (litres):
2.4
Engine Oil Classification API:
SG
Engine Oil Grade SAE:
10w/40
Engine Oil quantity with filter (litres):
3.3
Fork oil grade:
L01
Front Fork Oil cc (left leg):
101
Front Fork Oil cc (right leg):
101
Idle Speed (rpm):
1150 - 1250
Spark Plugs Gap (mm):
0.7 - 0.8
Valve Clearance Cold - Exhaust:
0.20 - 0.30
Valve Clearance Cold - Inlet:
0.10 - 0.20
Brakes
Front:
Twin Disc
Rear:
Disc
Dimensions
Wet Weight:
168 kg
Electrics
Voltage:
12v
Battery:
FTX12-BS
Spark Plugs (Iridium):
NGK CR9EIX
Engine
Type:
Liquid Cooled 4 Stroke Inline Four
Bore x Stroke:
73 X 59 mm
Displacement:
988 cc
Fuel Minimum Octane Rating:
95
Red line RPM:
12,500
Transmission
Chain Number of Links:
110
Chain type:
DID530
Sprocket front:
17
Sprocket rear:
42
Misc.
Motorcycle Style:
Sports
Tyres
Front:
120/70-ZR17 Tubeless
Rear:
190/50-ZR17 Tubeless
