Spec Sheet
The information below is specific to the Kymco - Dink 50 / Spacer 50 97, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Bike Info
CC:
50
Service
Cooling System (litres):
1.1
Final Drive grade:
90 W
Final Drive quantity:
100 cc
Fork oil grade:
ss 8
Front Fork Oil cc (left leg):
52
Front Fork Oil cc (right leg):
52
Idle Speed (rpm):
2000 - 2100
Spark Plugs Gap (mm):
0.6 - 0.7
Tyre Pressure Back Bar / psi:
33
Tyre Pressure Front Bar / psi:
25
Dimensions
Wet Weight:
119 kg
Electrics
Voltage:
12v
Ignition:
CDI
Spark Plugs:
BR6HSA NGK
Engine
Type:
Liquid Cooled 2 Stroke Single
Bore x Stroke:
39 x 41.4
Carburation:
Keihin PB058
Carburation Idle Jet:
35
Carburation Main Jet:
85
Displacement:
49.4 cc
Fuel Minimum Octane Rating:
92
Misc.
Place of Manufacture:
Kaohsiung Taiwan
Power
Max Power Output:
4.3 kw(5.7hp) @ 7000 rpm
Tyres
Front:
110/70-12
Rear:
130/70-12
