Spec Sheet
The information below is specific to the James - Super Swift M25 62-63, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.James - Super Swift M25 62
Bike Info
CC:
199
Chassis info:
1962 Prefix EM25 - xxx. 1963 Prefix FM25 - xxx.
Service
Gearbox Oil grade:
SAE 30
Points Gap mm:
(0.012 - 0.015 inch)
Spark Plugs Gap (mm):
(0.018 - 0.025 inch)
Brakes
Front:
Drum
Rear:
Drum
Front Drum Size:
6 inch
Rear Drum Size:
6 inch
Dimensions
Fuel Capacity:
2.75 gallons
Electrics
Voltage:
6v
Bulb-Headlight:
6v - 30 / 24w pre focus
Engine
Type:
Air Cooled 2 Stroke Parallel Twin
Bore x Stroke:
50mm x 63.5mm
Carburation:
Villiers S22 / 2
Displacement:
250 cc
Starting:
Kick
Transmission
Transmission:
4 Speed
Misc.
Place of Manufacture:
Birmingham England
Tyres
Front:
3.25 x 18 INCH
Rear:
3.25 x 18 INCH
Add information to the model
