Spec Sheet
The information below is specific to the CCM - LX 700-4A Quad 09, showing anything for service information to the amount of fork oil or even the tyre pressures. If you would like to contribute any missing information, please use the edit link below.
Back.Bike Info
CC:
700
Brakes
Front:
Disc
Rear:
Disc
Dimensions
Fuel Capacity:
17 litres
Height:
1225 mm
Length:
2250 mm
Wet Weight:
329 kgs
Width:
1210 mm
Electrics
Voltage:
12v
Ignition:
CDI
Engine
Type:
Liquid Cooled
Bore x Stroke:
102 x 84 mm
Compression Ratio:
9.2:1
Displacement:
686 cc
Starting:
Electric/Pull start
Transmission
Final Drive:
4 Wheel Drive Shaft
Transmission:
Low speed-high speed-neutral-reverse-parking
Misc.
Motorcycle Style:
Quad ATV
Place of Manufacture:
China
Power
Max Power Output:
13.0Kw 5500 rpm
Max Torque:
27.5N.m 4500 rpm
