Triumph (Meriden) T120R Bonneville 70

picture of bike
Service Info
Chain Freeplay mm 14
Coolant Air
Engine Oil Grade SAE 20w50
Engine Oil quantity (litres) 2.6
Fork oil grade Telescopic Fork oil
Front Fork Oil cc (left leg) 200
Front Fork Oil cc (right leg) 200
Gearbox Oil grade Hypoid 80/90
Gearbox Oil Litres 0.57
Idle Speed (rpm) 1000 hot
Points Gap mm .0015\'
Spark Plugs Gap (mm) .0025\'
Valve Clearance Cold - Exhaust .004\'
Valve Clearance Cold - Inlet .002\'

Triumph (Meriden) T120R Bonneville 69

picture of bike
Service Info
Chain Freeplay mm 14
Coolant Air
Engine Oil Grade SAE 20w50
Engine Oil quantity (litres) 2.6
Fork oil grade Telescopic Fork oil
Front Fork Oil cc (left leg) 200
Front Fork Oil cc (right leg) 200
Gearbox Oil grade Hypoid 80/90
Gearbox Oil Litres 0.57
Idle Speed (rpm) 1000 hot
Points Gap mm .0015\'
Spark Plugs Gap (mm) .0025\'
Valve Clearance Cold - Exhaust .004\'
Valve Clearance Cold - Inlet .002\'

Triumph (Meriden) T120R Bonneville 68

picture of bike
Service Info
Chain Freeplay mm 14
Coolant Air
Engine Oil Grade SAE 20w50
Engine Oil quantity (litres) 2.6
Fork oil grade Telescopic Fork oil
Front Fork Oil cc (left leg) 200
Front Fork Oil cc (right leg) 200
Gearbox Oil grade Hypoid 80/90
Gearbox Oil Litres 0.57
Idle Speed (rpm) 1000 hot
Points Gap mm .0015\'
Spark Plugs Gap (mm) .0025\'
Valve Clearance Cold - Exhaust .004\'
Valve Clearance Cold - Inlet .002\'
